300W Air to Liquid thermoelectric Cooler designed for Industrial laser and Medical diagnostics

300W Air to Liquid thermoelectric Cooler designed for Industrial laser and Medical diagnostics
300W Air to Liquid thermoelectric Cooler designed for Industrial laser and Medical diagnostics 300W Air to Liquid thermoelectric Cooler designed for Industrial laser and Medical diagnostics 300W Air to Liquid thermoelectric Cooler designed for Industrial laser and Medical diagnostics 300W Air to Liquid thermoelectric Cooler designed for Industrial laser and Medical diagnostics

Grote Afbeelding :  300W Air to Liquid thermoelectric Cooler designed for Industrial laser and Medical diagnostics

Productdetails:
Plaats van herkomst: CHINA
Merknaam: ADCOL
Certificering: ISO9001 , CE
Modelnummer: ATL300-24VDC
Betalen & Verzenden Algemene voorwaarden:
Min. bestelaantal: 1EA
Prijs: negotiable
Verpakking Details: Solid Carton -verpakking
Levertijd: 3 - 4 weken
Betalingscondities: T/T, PayPal
Levering vermogen: 500 stcs
Contact

300W Air to Liquid thermoelectric Cooler designed for Industrial laser and Medical diagnostics

beschrijving
P/n: ATL300-24VDC Koelmethode: Koele vloeistof
Stralende methode: Luchtmacht Omgevingstemperatuur/vochtigheid: -20 tot 60 ° C
Koelcapaciteit: 290 W Buitenste dim voor aansluiting: R10
Materiaal van de wisseler: Al met harde oxidatie Hot/koude zijventilatorstroom: 0.9A / NA
Tem nominale/opstartstroom: 13.5a/17.5a Nominale/max spanning: 24/30 VDC
Algemene dimensie: 260 mm x 158 mm x 160 mm lawaai: 52 dB
Gewicht: 5,5 kg Levenstijd: > = 70.000 Hou
Tolerantie: 10%

Adcol Peltier Thermal Cooler is your perfect choice for any Industrial, Commercial or Home application. Adcol is a well-known brand name from China and all of our Peltier Thermoelectric Modules have been certified with ISO9001 and CE.

The solid carton packaging ensures secure delivery and payment terms include T/T and Paypal. We guarantee a supply ability of 500pcs per month.



ATL300-24VDC  Air to Liquid thermoelectric Cooler Assembly



1.Product Introduction

The ATL300-24VDC Thermoelectric air liquid is designed for cooling objects via liquid to transfer heat.

Heat is absorbed through a liquid exchanger and dissipated by high density heatsink with fan.
It could remove up to 290W cooling, and is available in 24VDC configurations. Also it is virtually
maintenance-free, and can be mounted in any orientation, offering design flexibility with solid-state reliability.

300W Air to Liquid thermoelectric Cooler designed for Industrial laser and Medical diagnostics 0


2.Features



  • 290W capacity rated at ΔT = 0ºC,Tambient = 30°C
  • Refrigerant free - environmentally friendly
  • Wide operating temperature range of –20°C to +60°C
  • Shift between heating and cooling without using a heater
  • Reduced noise and vibration with no moving parts

3.Application

  • Analytical instrument
  • Medical diagnostics
  • Industrial laser
  • Medical laser


4. Performance Curve

300W Air to Liquid thermoelectric Cooler designed for Industrial laser and Medical diagnostics 1

5.Drawing
300W Air to Liquid thermoelectric Cooler designed for Industrial laser and Medical diagnostics 2

300W Air to Liquid thermoelectric Cooler designed for Industrial laser and Medical diagnostics 3300W Air to Liquid thermoelectric Cooler designed for Industrial laser and Medical diagnostics 4

label:

Peltier vloeistofkoeler,

thermo-elektrische koeler,

Peltier vloeistofkoelsysteem
